PVC Suction
NORTH DAKOTA PART NUMBER
HPS
Application
Heavy duty water suction and discharge hose for use in industrial, construction, and agricultural applications.
Construction
Flexible PVC, rigid PVC helix, smooth bore, smooth O.D. Reinforcement- Woven high tensile synthetic yarn
Temperature Range
-13°F to 140°F
| Part Number | I.D. Inches | O.D. Inches | MAX W.P. (PSI) | APPROX. WT. PER. FT. LBS. |
| HPS075 | 3/4 | 0.95 | 86 | 0.16 |
| HPS100 | 1 | 1.25 | 86 | 0.26 |
| HPS125 | 1-1/4 | 1.52 | 79 | 0.37 |
| HPS150 | 1-1/2 | 1.81 | 72 | 0.44 |
| HPS200 | 2 | 2.38 | 72 | 0.74 |
| HPS250 | 2-1/2 | 2.92 | 72 | 1.01 |
| HPS300 | 3 | 3.41 | 62 | 1.21 |
| HPS400 | 4 | 4.50 | 55 | 2.01 |
| HPS500 | 5 | 5.55 | 33 | 2.45 |
| HPS600 | 6 | 6.67 | 33 | 3.37 |
| HPS800 | 8 | 8.82 | 28 | 5.8 |
