Food & Beverage

White Creamery/Paper Mill

NORTH DAKOTA PART NUMBER
H113S
Application
Cold and hot water up to 212°F (100°C) where steam is injected into the water. Used for paper mill, food handling or processing plant washdown service requiring hose with a non-marking cover.
Construction
Tube: Type P (EPDM) Black. Reinforcement: Braided, high tensile synthetic textile cord. Cover: Type P (EPDM) White.
Temperature Range
-20°F to +180°F (-29°C to +82°C) continuous service. For nozzle only. -40°F to +212°F (-40°C to +100°C) continuous service.
Part NumberI.D. InchesO.D. InchesMAX W.P. (PSI)Approx. Wt. Per. Ft. Lbs.
H113S0501/20.912000.28
H113S0753/41.252000.49
H113S10011.522000.65
